HT-RTG
Rubber Tyred Gantry Crane
Yard stacking on rubber tyres — moves between blocks without rails, so the yard layout stays flexible.
Capacity 35 – 50 T
Span 6 + 1 to 8 + 1 rows
Duty class A6 – A8
How it is built
RTGs stack containers in the yard and can relocate between blocks under their own power, which is what makes them the default for terminals that expect their layout to change. Rubber tyred running means no rail civil works, at the cost of higher ground pressure — so we size the wheel arrangement to the pavement you actually have.
Configuration
- Diesel-electric or electrified (cable reel / busbar) drive
- Auto-steering and gantry positioning
- Anti-sway and container landing assist
- Twin-lift spreader option
- Eight or sixteen wheel arrangement to suit pavement loading
Technical data
- Rated capacity
- 35 – 50T
- Stacking
- 1 over 5 high
- Span
- 6 + 1 to 8 + 1 rows
- Lift height
- 15 – 18M
- Hoist speed (rated)
- 23 – 28m/min
- Gantry travel
- 70 – 130m/min
- Steering
- 90° cross-travel
Typical applications
- Container yard stacking
- Inland container depots (ICD)
- Rail-served terminals
Request for quotation
Specify a rtg for your duty
Ranges above are the envelope we build within. Send your actual capacity, span and lift height and we will engineer to it.
